Ceramic fiber Boards

Name: Ceramic fiber Boards
Brand: ESS ESS CERATECH
Price: 750.0 INR
Availability: InStock

Price 750.0 INR/ Unit

Get a Price/Quote

MOQ : 50 Units

Ceramic fiber Boards Specification

Thermal Conductivity
Calorie (IT)/second/centimeter/°C

Density
350 Gram per cubic centimeter(g/cm3)

Feature
Lightweight, thermal shock resistant, low thermal conductivity

Product Type
Ceramic White Boards

Material
Ceramic Fiber

Tensile Strength
>0.5 MPa

Width
610 mm (can be customized)

Thickness
10 mm - 50 mm

Application
Industrial and Outdoor

Heat Conductivity
Low (0.035-0.045 W/mK)

Color
Grey

Max Withstanding Temperature
1260C - 1430C

Rated Current
Statampere (sA)

Sound Absorption
Excellent

Shrinkage (at 1000C)
<2%

Water Absorption
<1.5%

Compressive Strength
0.4-1.0 MPa

Bulk Density
240-320 kg/m3

Odor
Odorless

Chemical Composition
Al2O3, SiO2, Small amount of ZrO2

pH Value
Neutral

Eco-Friendly
Asbestos free, non-toxic

Thermal Expansion
Very low

Ceramic fiber Boards Trade Information

Minimum Order Quantity
50 Units

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
500 Units Per Month

Delivery Time
7 Days

Sample Policy
Contact us for information regarding our sample policy

Main Export Market(s)
Asia

Main Domestic Market
All India

Ceramic fiber Boards About

With support from our active team experts, we are involved in offering excellent quality Ceramic White Boards. These boards are used for flue & chimney linings in furnaces or kilns and industrial heat shields and thermal barriers. Ceramic White Boards have an ability to protect refractory surfaces from thermal shock and chemical attack. Moreover, these boards are also able to withstand on high temperature.

Ceramic fiber boards are high-temperature insulation materials made from ceramic fibers. Here's an overview:

Key Features

Low Thermal Conductivity: Provides excellent thermal insulation, reducing heat transfer and energy loss

Rigid Structure: Maintains shape and structure even at high temperatures

Chemical Resistance: Resistant to many chemicals, including acids and alkalis

Applications

Industrial Furnaces: Used in high-temperature furnaces, kilns, and ovens

Heat Treatment: Used in heat treatment applications, such as annealing, tempering, and quenching

Aerospace: Used in aerospace applications, such as heat shields and thermal protection systems

Automotive: Used in automotive applications, such as catalytic converters and exhaust systems

Benefits

Energy Efficiency: Reduces heat loss and energy consumption

HighTemperature Resistance: Withstands extremely high temperatures, making it ideal for demanding applications

Structural Integrity: Maintains shape and structure even at high temperatures

Chemical Resistance: Resistant to many chemicals, reducing the risk of degradation or damage

Types

Standard Ceramic Fiber Boards: Made from standard ceramic fiber materials

High-Purity Ceramic Fiber Boards: Made from high-purity ceramic fiber materials for improved performance

Vacuum-Formed Ceramic Fiber Boards: Made using a vacuum-forming process for precise shapes and dimensions

Manufacturers

Some manufacturers of ceramic fiber boards include companies specializing in high-temperature insulation materials and solutions

Exceptional Thermal Performance

Thanks to their low heat conductivity and high-temperature resistance, these ceramic fiber boards are an ideal choice for demanding industrial environments. They maintain structural integrity under thermal stress and effectively contain heat, reducing energy consumption in furnaces, kilns, or outdoor settings.

Versatile and Eco-Friendly Material

Produced without asbestos or toxic substances, our ceramic fiber boards are an environmentally responsible solution for thermal insulation. With excellent sound-absorbing qualities and neutral pH, they safely improve working conditions in various industrial applications.

FAQ's of Ceramic fiber Boards:

Q: How do ceramic fiber boards resist high temperatures in industrial applications?

A: Ceramic fiber boards are composed of Al2O3, SiO2, and a small amount of ZrO2, granting them exceptional thermal stability. Their low shrinkage (<2% at 1000C) and high withstanding temperatures (1260C to 1430C) make them suitable for continuous use in furnaces, kilns, and other high-temperature environments.

Q: What advantages does the low thermal conductivity of these boards offer?

A: With low thermal conductivity (0.035-0.045 W/mK), these boards significantly minimize heat loss, leading to energy savings and improved temperature control in insulation projects. This property helps maintain safe and stable environmental conditions.

Q: Where can ceramic fiber boards be installed?

A: They are ideal for both industrial and outdoor settings, including applications in heat shielding, furnace linings, boiler insulation, and equipment protection. Their weather-resistant properties make them versatile for multiple installation locations.

Q: How are custom sizes for width and thickness accommodated?

A: The standard width is 610 mm, but sizes can be customized upon request. Thickness options range from 10 mm to 50 mm, ensuring suitability for various insulation needs and space requirements.

Q: What processes are involved in installing ceramic fiber boards?

A: Installation generally involves cutting the boards to fit designated spaces and securing them with suitable fasteners or adhesives. Their lightweight nature simplifies handling and placement, promoting fast, hassle-free assembly.

Q: What are the key benefits of using ceramic fiber boards over traditional insulating materials?

A: Ceramic fiber boards are lightweight, asbestos-free, and non-toxic. They exhibit excellent sound absorption, very low water absorption, and resist thermal shock, reducing maintenance costs and offering safer performance compared to conventional insulation materials.
